All new

 Repair and Ugrade antenna

  Our HA-0218G-NF has a more uniform gain and antenna factor because of the better behavior of its radiation pattern. Has an enormous broad frequency range from 2GHz to 18GHz and very high input powers reach 300W. The gain increases with increasing frequency up to a max of 17 dBi. Model: HA-0218G-NF Freq: 2GHz to 18GHz Gain: 5dBi to 17dBi

Model: HA-08M18G- NF  Frequency: 0.8GHz to 18 GHz Gain: 3dBi-18dBi Our broadband horn antenna covers the frequency range from 800MHz to GHz with a gain from 3dBi to 18 dBi VSWR is 2:1 and Vertical or Horizontal Polarization. Moreover, we also have the broadband horn antenna that covers the frequency range from 5GHz to 70GHz.

To preserve the product well as well suitable for national or international projects, the accompanying protective box is indispensable. Please contact us for more details on product prices as well as other accompanying products.

Product No. Description Frequency Polarization Dimension Weight Connector HA-0570GB1-VF                                5 GHz to 70 GHz Double Ridged Broadband Waveguide Horn Antenna, V-Female Connector (1.85mm) 5 to 70 GHz                    Horizontal or Vertical 38x55x74mm 50 V-Female HR-0540GB-KF 5 GHz to 40 GHz Open Boundary Quad-Ridged Horn Antenna, 2.92mm-Female connector 5 to 40 GHz Horizontal and Vertical or ±45deg 55x55x61mm 53 K-Female*2 HR-0570GB-VF 5 GHz to 70 GHz Open Boundary Quad-Ridged Horn Antenna, 1.85mm-Female connector 5 to 70 GHz Horizontal and Vertical or ±45deg 55x55x61mm 55 V-Female*2

Antenna Category Antenna Frequency XX - RF Microwave Antenna  XXXXX- Frequency  HA Double Ridged Horn Antenna 0210G 2GHz-10GHz HB Open Boundary Double Ridge Horn Antenna 03M06G 300MHz-6GHz HQ Quad-Ridged Horn Antenna 065M08G 650MHz-8GHz HR Open Boundary Quad-Ridged Horn  Antenna 1840G 18GHz-40GHz VC Vivaldi Antenna 01G18G 1GHz-18GHz LO  Log Periodic Antenna  01G08G 1GHz-8GHz For Standard Gain Horn series     HS Standard Gain Horn Antenna 28 WR28 waveguide WC Waveguide to Coaxial Adapter 90 WR90 waveguide WI Waveguide Horn Antenna (without adapter) 2100 WR2100 Waveguide For Other     SL Sleeve Dipole Antenna      LM Antenna tripod
