PRECISION RF CABLE SOLUTIONS

Cable Assembly

High-Performance RF Cable Assembly Series: FT-RF professional Cable Assemblies are engineered for high-precision laboratory testing and demanding microwave environments.

Featuring advanced ZT-series shielding technology, these cables provide exceptional phase stability and ultra-low insertion loss up to 40 GHz. Designed for peak Signal Integrity, each assembly undergoes rigorous quality control to ensure reliable performance across critical RF interconnect applications.

*Custom lengths and specialized connector configurations (N-type, TNC, etc.) are available upon request to meet your specific measurement needs.

⚡ Next-Gen Engineering Highlights

Up to 40 GHz Bandwidth

Continuous millimeter-wave transmission with ultra-low insertion loss for high-frequency VNA bench testing.

Phase-Stable ZT Shielding

Multi-layer triple-shielded architecture ensures superior flexure stability and high phase integrity.

Precision Connector Pinning

Passivated stainless steel 2.92mm and SMA connectors for high mating durability and tight tolerances.

50 Ohm Impedance Match

Optimized internal transitions guarantee low VSWR and clean signal transmission in test setups.

Key Operational Applications:

Cable Assembly ZT40 Cable 2.92mm Connector 40GHz Test Cable Signal Integrity

📡 1. ZT40 Millimeter Wave Series (Up to 40 GHz)

Model / Configuration	Length	Connector Interface
ZT40 High-Precision Cable	1.0 Meter	2.92mm (Male) to 2.92mm (Male)
ZT40 High-Precision Cable	1.2 Meters	2.92mm (Male) to 2.92mm (Male)
Frequency Range & Stability	DC to 40 GHz	Excellent Phase Stability

📡 2. ZT26S Microwave Series (Up to 26.5 GHz)

Model / Configuration	Length	Connector Interface
ZT26S Precision Cable	1.2 Meters	SMA (Male) to SMA (Male)
Frequency Range & Focus	DC to 26.5 GHz	Optimized for Microwave Testing
Nominal Impedance & Tech	50 Ohm	Low Loss Shielding Technology
