Description & Specification
HS-340-UDR-10A-NF WR-340 Horn Antenna
Professional S-Band Antennas | Standard Gain Waveguide Horn | 2.2 GHz – 3.3 GHz | 10 dBi
The HS-340-UDR-10A-NF is a high-performance S-band standard gain waveguide horn antenna professionally engineered for laboratory and spectrum monitoring environments across the 2.2 GHz to 3.3 GHz spectrum. It features a specialized 54° wide beamwidth design for highly efficient signal coverage, eliminating the need for frequent realignments. Boasting a standard UDR waveguide flange interface, a premium N-Female connector, and a precision compact aerospace-grade aluminum body, this antenna provides outstanding Signal Security, symmetrical radiation control, and long-term mechanical integrity.
Electrical & RF Performance
| Frequency Range | 2.2 - 3.3 GHz |
| Gain (Typical) | 10 dBi |
| Peak Power (CW) | 360 Watts |
| V.S.W.R (Max) | 1.25 : 1 |
| 3dB Beamwidth (H/E) | 54° / 54° |
Mechanical & Interface Data
| Flange Interface | UDR |
| Connector Type | N-Female |
| Dimensions (L x W x H) | 123 x 162 x 358 mm |
| Weight | 1500g |
54° Wide Coverage
Engineered for high-efficiency signal capture and broad environment monitoring without the need for frequent realignments.
Compact Aerospace Build
Smaller footprint (123mm width) compared to high-gain models, making it ideal for space-constrained measurement setups.
Stable Signal Reception
Symmetrical radiation pattern and precision-machined aluminum body ensure consistent 10 dBi gain across the S-band spectrum.
Optimized Integrity
Delivers continuous 360 Watts power handling performance, securing uncompromised Signal Security during broadband validation tasks.
Inquire About Professional Horn Solutions
Contact our engineering team for specialized gain calibration data, custom mounting solutions, or technical support regarding high-gain broadband setups.
