Description & Specification
SL-3150-SF Precision Reference Antenna
S-Band Reference Grade Radiator | CTIA Symmetry Compliant | 3000 MHz – 3300 MHz
The SL-3150-SF is a laboratory-standard Precision Sleeve Dipole Antenna specifically engineered for OTA (Over-the-Air) performance validation and anechoic chamber calibration within the S-band spectrum. Engineered to satisfy strict CTIA ± 0.1 dB symmetry compliance standards, this premium reference radiator ensures that the omnidirectional radiation pattern remains exceptionally uniform for highly accurate ripple test measurements. Its specialized structural sleeve balun isolates the feedpoint from cable-induced surface waves and interference, guaranteeing the strict Signal Integrity required for professional gain references, low-gain antenna efficiency characterization, and electronic shielding evaluations. Developed and precision-machined in Taiwan, it serves as an indispensable reference standard for high-fidelity wireless test facilities.
RF & Calibration Performance
| Frequency Range | 3000 MHz to 3300 MHz (S-Band) |
| Nominal Gain | 2.15 dBi ± 1 dBi |
| Pattern Symmetry | ± 0.1 dB (CTIA Symmetry Compliant) |
| Antenna Radiator Type | Sleeve Dipole (Reference Grade Standard) |
Mechanical & Hardware Data
| Standard Coaxial Connector | SMA-Female (Premium Interface) |
| Custom Connector Interface | N-Female Interface Option Available Upon Request |
| Dimensions (L x W x H) | 145 x 26 x 26 mm |
| Net Weight (N.W.) | 100 g (Ultra-Lightweight Profile) |
| Manufacturing Origin | Taiwan Design & Manufactured (FT-RF) |
CTIA Symmetry Precision
Engineered to satisfy rigorous ± 0.1 dB symmetry protocols, providing world-class electromechanical stability for OTA chamber reflectivity evaluation and advanced spatial ripple tests.
Feed Point Contact Isolation
The specialized sleeve choke configuration prevents the feed cable from interacting with the antenna aperture elements, ensuring a completely unperturbed, symmetric toroidal radiation pattern.
Taiwanese Engineering Excellence
Precision designed and manufactured in Taiwan under strict quality control standards, ensuring structural uniformity, concentric alignment, and reliable phase center calibration.
Reference Grade Dominance
Serves as a reliable low-gain gain reference and absolute efficiency standard for calibrating S-band tactical monitoring receivers, network simulation platforms, and electronic shielding setups.
Get a Quote / Custom RF Calibration
Contact our technical engineering team to obtain certified anechoic calibration data sheets, specific V.S.W.R plot metrics, or specialized fiber-optic mount adapters for your testing facility.
