2GHz to 18GHz Open Boundary Quad-Ridged Broadband Horn Antenna
Dual Linear Polarization | Precision SMA-Female | Model: HR-0218G-SF
The HR-0218G-SF is an Open Boundary Quad-Ridged Broadband Waveguide Horn Antenna professionally engineered and manufactured by Fei Teng Wireless Technology Co., Ltd. (FT-RF) in Taiwan. Designed to operate continuously across the multi-octave microwave frequency spectrum from 2 GHz to 18 GHz, it provides dual-linearly polarized capability with high cross-polarization isolation and broad radiation coverage. Featuring an open boundary quad-ridged construction with an aperture profile measuring 156.82 x 156.82 mm and an overall length of 188 mm, it is built from high-precision aluminum alloy weighing approximately 878.53 g. Equipped with precision SMA-Female coaxial feeds and an integrated mounting flange with M3 and M5 threaded patterns (40.00 / 65.00 mm PCD), this antenna is an essential standard for anechoic chamber calibration, dual-polarized EMC/EMI measurements, and radar target simulation.
Technical Specifications
| Frequency Range | 2 - 18 GHz |
| Antenna Type | Open Boundary Quad-Ridged Horn |
| Polarization | Dual Linear (Horizontal & Vertical) |
| Impedance | 50 Ω |
| Connector | SMA-Female |
Mechanical & Physical Data
| Dimensions (W x H x L) | 156.82 x 156.82 x 188.00 mm |
| Antenna Weight (N.W) | 878.53 g |
| Body Material | High-Precision Aluminum Alloy |
| Mounting Interface | Flange with M3 Countersunk & M5.00 (P.C.D 40 / 65 mm) |
| Country of Origin | Taiwan |
Gain Calibration Plot
Calibration in Progress
Laboratory measurement data pending official upload. Available upon request.
VSWR Performance Curve
Calibration in Progress
Laboratory measurement data pending official upload. Available upon request.
3dB Beamwidth Radiation Pattern
Calibration in Progress
Laboratory measurement data pending official upload. Available upon request.
Key Design & Feature Highlights
Quad-Ridged Open Structure
Open boundary geometry minimizes aperture reflections while delivering symmetrical dual-polarized operation.
Broadband 2 to 18 GHz
Continuous microwave coverage designed for wideband chamber characterization and radar signal detection.
Precision SMA-Female Feeds
Equipped with durable 50-ohm SMA-Female connectors delivering high RF repeatability and stability.
Taiwanese Precision
Manufactured from precision CNC aluminum alloy in Taiwan for maximum dimensional accuracy.
Contact FT-RF Engineering Division
Contact our technical engineering division today to request official quotes or customized mounting solutions.
