MILLIMETER WAVE (18.0 GHz – 75.0 GHz)
Millimeter Wave Standard Gain Horn Antennas
Calibrated Millimeter Wave Standard Gain Horn Antennas covering V, Q, Ka, and K bands (WR15 to WR42). Integrated with precision low-loss Waveguide-to-Coaxial Adapters for seamless laboratory integration and reliable gain reference calibration.
Ideal reference standards for 5G FR2 / 6G research, automotive radar calibration, and anechoic chamber gain comparisons.
*Individual calibration certificates and precision alignment flanges available upon request.
⚡ Core Engineering Highlights
18.0 – 75.0 GHz Spectrum
Covers V, Q, Ka, and K millimeter-wave bands from WR15 to WR42.
Reference Gain Accuracy
Precision electroformed pyramidal horns with nominal gain options up to 25 dBi.
Integrated Adapter Assembly
Factory-assembled with precision coax adapters for immediate test bench connection.
RoHS Compliant
Fully compliant with international environmental and durability standards.
Covered Waveguide Models & Frequency Chips:
| Waveguide Standard | Frequency Range | Target Applications | Model Link |
|---|---|---|---|
| WR15, WR19, WR22 | 33.0 GHz – 75.0 GHz (V / Q Band) | 6G Research, Sub-THz R&D, Chamber OTA Calibration | |
| WR28, WR34, WR42 | 18.0 GHz – 40.0 GHz (Ka / K Band) | 5G FR2 Gain Calibration, Satellite Payload Test |
🛠️ Customization & Calibration Options
- Individual Traceable Gain Calibration Reports
- Precision Flange Mounting Pin Options
- Phase-Matched Horn Pairs for Array System Calibration
📐 Recommended Testing Accessories
HS-051-UBR-25A-KF
WR51(15 to 22GHz)K-Female 25dbi Stand Gain Waveguide Horn Antenna Flange:UBR
View Details
FT-RF
| Frequency Range: | 15 - 22 GHz |
| Antenna Type: | Standard Gain Horn |
| Nominal Gain: | Standard (Horn) |
| Waveguide Size: | WR51 (UBR) |
| Stock: | 0 |
| 2026/06/10 | |
HS-019-UG-25A-VF
WR19 (40 to 60GHz), 25 dbi Standard Gain Waveguide Horn Antenna, Flange: UG
View Details
FT-RF
| Frequency Range: | 40.0 - 60.0 GHz |
| Antenna Type: | Standard Horn Antenna |
| Nominal Gain: | 25 dBi Typical |
| Waveguide Size: | WR-19 (K-Female) |
| Stock: | 0 |
| 2026/06/24 | |
HS-019-UG-20A-VF
WR19 (40 to 60GHz), 20dbi Standard Gain Waveguide Horn Antenna, Flange: UG
View Details
FT-RF
| Frequency Range: | 40.0 - 60.0 GHz |
| Antenna Type: | Standard Horn Antenna |
| Nominal Gain: | 20 dBi Typical |
| Waveguide Size: | WR-19 (K-Female) |
| Stock: | 0 |
| 2026/06/24 | |
HS-019-UG-15A-VF
WR19 (40 to 60GHz), 15 dbi Standard Gain Waveguide Horn Antenna, Flange: UG
View Details
FT-RF
| Frequency Range: | 40.0 - 60.0 GHz |
| Antenna Type: | Standard Horn Antenna |
| Nominal Gain: | 15 dBi Typical |
| Waveguide Size: | WR-19 (K-Female) |
| Stock: | 0 |
| 2026/06/24 | |
HS-019-UG-10A-VF
WR19 (40 to 60GHz), 10dbi Standard Gain Waveguide Horn Antenna, Flange: UG
View Details
FT-RF
| Frequency Range: | 40 - 60 GHz |
| Standard Gain: | 10 dBi |
| Max Power (W): | 60 Watts |
| Connector: | K-Female |
| Stock: | 0 |
| 2026/08/21 | |
NEW
HS-022-UG-25A-VF
WR22 (32.9 to 50.1GHz), 25 dbi Standard Gain Waveguide Horn Antenna, Flange: UG V-Female(1.85mm)
View Details
FT-RF
| Frequency Range: | 32.9 - 50.1 GHz |
| Antenna Type: | Standard Horn Antenna |
| Nominal Gain: | 25 dBi Typical |
| Waveguide Size: | WR-22 (UG Flange / 1.85mm V-F) |
| Stock: | 0 |
| 2026/08/21 | |
NEW
HS-022-UG-20A-VF
WR22 (32.9 to 50.1GHz), 20 dbi Standard Gain Waveguide Horn Antenna, Flange: UG V-Female(1.85mm)
View Details
FT-RF
| Frequency Range: | 32.9 - 50.1 GHz |
| Antenna Type: | Standard Horn Antenna |
| Nominal Gain: | 20 dBi Typical |
| Waveguide Size: | 1.85mm V-Female (80W) |
| Stock: | 0 |
| 2026/08/21 | |
NEW
HS-022-UG-15A-VF
WR22 (32.9 to 50.1GHz) 15dbi Standard Gain Waveguide Horn Antenna, Flange: UG V-Female (1.85mm)
View Details
FT-RF
| Frequency Range: | 32.9 - 50.1 GHz |
| Antenna Type: | Standard Horn Antenna |
| Nominal Gain: | 15 dBi Typical |
| Waveguide Size: | 1.85mm V-Female (80W) |
| Stock: | 0 |
| 2026/08/21 | |
NEW
HS-022-UG-10A-VF
WR22 (32.9 to 50.1GHz), 10dbi Standard Gain Waveguide Horn Antenna, Flange: UG V-Female(1.85mm)
View Details
FT-RF
| Frequency Range: | 32.9 - 50.1 GHz |
| Antenna Type: | Standard Horn Antenna |
| Nominal Gain: | 10 dBi Typical |
| Waveguide Size: | 1.85mm V-Female (80W) |
| Stock: | 0 |
| 2026/08/21 | |
NEW
HS-042-UBR-15E-KF
WR42 18 GHz to 26.5 GHz 15dbi Standard Gain Waveguide Horn Antenna, E-plane sectoral Horn Antenna, UBR Flange, K-Female Connector
View Details
FT-RF
| Frequency Range: | 18 - 26.5 GHz |
| Standard Gain: | 15 dBi |
| Connector Type: | K-Female (2.92mm) |
| Waveguide Size / Flange: | WR-42 / UBR Style |
| Lead Time: | 📩 info-tw@ft168.com.tw |
| Stock Status: | Contact us |
| 2026/08/21 | |
HS-028-UBR-15E-KF
WR28 26.5 GHz to 40 GHz 15dbi E-Plane Sectoral Flange: UBR Standard Gain Waveguide Horn Antenna
View Details
FT-RF
| Frequency Range: | 26.5 - 40.0 GHz |
| Antenna Type: | Waveguide to Coaxial Adapter |
| Nominal Gain: | 250 Watts (CW) |
| Waveguide Size: | WR-28 (K-Female 2.92mm) |
| Stock: | 0 |
| 2026/08/21 | |
HS-034-UBR-20A-KF
WR-34 22GHz to 33GHz 20dbi Standard Gain Waveguide Horn Antenna K-Female Connector Flange: UBR UG-1530/U
View Details
FT-RF
| Frequency Range: | 22.0 - 33.0 GHz |
| Antenna Type: | Waveguide to Coaxial Adapter |
| Nominal Gain: | 200 Watts (CW) |
| Waveguide Size: | WR-34 (K-Female 2.92mm) |
| Stock: | 0 |
| 2026/08/21 | |
