2 to 18GHz Open Boundary Double Ridged Horn Antenna
45° Wide Angle, 2.92mm Female Connector
This antenna is an open boundary double ridged horn antenna operating from 2 GHz to 18 GHz. It features a 45° wide beamwidth and is equipped with a 2.92mm female connector. It is suitable for broadband testing, communication, and monitoring applications.
Modular & System Integration Ready:
Designed with modularity in mind, this antenna can be easily integrated into multi-antenna systems or configured as a standalone module. This flexibility provides optimal installation solutions for complex RF testing environments.
Technical Specifications
| Frequency Range | 2 GHz – 18 GHz |
| Connector | 2.92mm Female |
| Beamwidth | 45° (Horizontal/Vertical) |
| Polarization | Linear (Vertical/Horizontal selectable) |
| Gain | Approx. 5 – 18 dBi (varies with frequency) |
| Material | Aluminum alloy body, optional surface treatment |
| Application Environment | Indoor / Test Environment |
