KU-BAND & X-BAND (8.2 GHz – 22.0 GHz)
Ku-Band & X-Band Standard Gain Horn Antennas
High-gain Ku-Band & X-Band Waveguide Horn Antennas (WR51, WR62, WR75, and WR90). These standard gain horns serve as primary calibration benchmarks for defense radar systems, satellite ground terminals, VSAT links, and military EMC compliance test chambers.
Featuring high linear polarization purity (>30 dB cross-polarization rejection) and uniform radiation patterns across 8.2 GHz to 22.0 GHz.
*CPR, FDP, and FBP flange options and weather-proof outdoor radomes available upon request.
⚡ Core Engineering Highlights
8.2 – 22.0 GHz Coverage
Full-band operation matching standard Ku and X band rectangular waveguides.
High Linear Purity
Cross-polarization rejection >30 dB for accurate dual-polarized radiation tests.
Defense Radar Standard
Widely adopted for X-band and Ku-band radar cross-section (RCS) testing.
Stable Gain Curve
Flat gain response over full operational bandwidth with VSWR <1.25:1.
Covered Waveguide Models & Frequency Chips:
| Waveguide Standard | Frequency Range | Target Applications | Model Link |
|---|---|---|---|
| WR51 | 15.0 GHz – 22.0 GHz | Upper Ku / K-Band Comms, Telemetry Feeds | |
| WR62 | 12.4 GHz – 18.0 GHz (Ku-Band) | VSAT Terminals, Airborne Radar, Microwave Links | |
| WR75 | 10.0 GHz – 15.0 GHz | SatCom Ground Links, Telemetry, Radar Testing | |
| WR90 | 8.2 GHz – 12.4 GHz (X-Band) | Weather Radar, Marine Radar, Military EMC Test |
🛠️ Customization & Engineering Options
- CPR / FDP / FBP Flange Custom Configurations
- High-Power Continuous Wave Input Feed Horns
- Custom Aircraft-Grade Aluminum Anodization
📐 Recommended Testing Accessories
HS-051-UBR-25A-KF
WR51(15 to 22GHz)K-Female 25dbi Stand Gain Waveguide Horn Antenna Flange:UBR
View Details
FT-RF
| Frequency Range: | 15 - 22 GHz |
| Antenna Type: | Standard Gain Horn |
| Nominal Gain: | Standard (Horn) |
| Waveguide Size: | WR51 (UBR) |
| Stock: | 0 |
| 2026/06/10 | |
HS-062-UDR-10H-SF
WR62 Waveguide, 12.4 to 18GHz,10dbi Standard Gain Waveguide Horn Antenna, H-Plane Sectoral, Flange: UBR, SMA-Female connector
View Details
FT-RF
| Frequency Range: | 12.4 - 18.0 GHz |
| Antenna Type: | Standard Horn Antenna |
| Nominal Gain: | 10 dBi Typical |
| Waveguide Size: | WR-62 (UG-2664/U / SMA-F) |
| Stock: | 0 |
| 2026/06/24 | |
NEW
HS-062-20-R-NF
WR62 12.4 GHz to 18 GHz 20 dbi Standard Gain Horn Antenna with Radome, UDR Flange, N-Female Connector
View Details
FT-RF
| Frequency Range: | 12.4 - 18.0 GHz |
| Antenna Type: | Standard Horn Antenna |
| Nominal Gain: | 20 dBi (350W) |
| Waveguide Size: | WR-62 |
| Stock: | 0 |
| 2026/06/09 | |
NEW
HS-062-10-R-SF
WR62 12.4 GHz to 18 GHz 10 dbi Standard Gain Horn Antenna with Radome, UDR Flange, SMA Female Connector
View Details
FT-RF
| Frequency Range: | 12.4 - 18.0 GHz |
| Antenna Type: | Standard Horn Antenna |
| Nominal Gain: | 10 dBi Typical |
| Waveguide Size: | WR-62 Horn |
| Stock: | Contact us |
| 2026/06/25 | |
NEW
HS-062-20-R-SF
WR62 12.4 GHz to 18 GHz 20 dbi Standard Gain Horn Antenna with Radome, UDR Flange, SMA Female Connector
View Details
FT-RF
| Frequency Range: | 12.4 - 18.0 GHz |
| Antenna Type: | Standard Horn Antenna |
| Nominal Gain: | 20 dBi Typical |
| Waveguide Size: | WR-62 Horn |
| Stock: | Contact us |
| 2026/06/25 | |
HS-062-UBR-25A-SF
WR62 Standard Gain Horn Antenna, 12.4 to 18 GHz, 25dbi, SMA-Female Connector, UBR Flange
View Details
FT-RF
| Frequency Range: | 12.4 - 18.0 GHz |
| Antenna Type: | Standard Horn Antenna |
| Nominal Gain: | 25 dBi Typical |
| Waveguide Size: | WR-62 (UG-419/U / SMA-F) |
| Stock: | 0 |
| 2026/06/24 | |
FT-RF
| Frequency Range: | 15.0 - 22.0 GHz |
| Antenna Type: | Standard Horn Antenna |
| Nominal Gain: | 20 dBi Typical |
| Waveguide Size: | WR-51 (No Adapter / 500W) |
| Stock: | 0 |
| 2026/06/09 | |
FT-RF
| Frequency Range: | 15.0 - 22.0 GHz |
| Antenna Type: | Standard Horn Antenna |
| Nominal Gain: | 15 dBi Calibrated (77°×16° Fan-Beam) |
| Waveguide Size: | WR-51 (UBR Style / 500W) |
| Stock: | 0 |
| 2026/06/22 | |
WI-51-UBR-10H
WR51 15 GHz to 22 GHz 10dBi H-Plane Sectoral Horn Antenna Waveguide Input Flange: UBR
View Details
FT-RF
| Frequency Range: | 15.0 - 22.0 GHz |
| Antenna Type: | H-Plane Sectoral Horn |
| Nominal Gain: | 10 dBi (16°×100° Fan-Beam) |
| Waveguide Size: | WR-51 (UBR / 500W) |
| Stock: | 0 |
| 2026/06/22 | |
HS-051-UBR-20A-KF
WR51 15 to 22 GHz 20dbi Standard Gain Waveguide Horn Antenna, K-Female Connector
View Details
FT-RF
| Frequency: | 15 - 22 GHz |
| Type: | WR-51 Horn |
| Gain: | 20 dBi |
| Stock: | 0 |
| 2026/06/24 | |
HS-051-UBR-10A-KF
WR51 Standard Gain Waveguide Horn Antenna, 15 GHz to 22 GHz, 10dbi, K-Female Connector
View Details
FT-RF
| Frequency: | 15 - 22 GHz |
| Type: | WR-51 Horn |
| Gain: | 10 dBi |
| Stock: | 0 |
| 2026/06/24 | |
HS-062-UBR-10A-SF
WR62 12.4 GHz to 18 GHz 10dbi Standard Gain Waveguide Horn Antenna SMA-Female Connector Flange: UDR
View Details
FT-RF
| Frequency: | 12.4 - 18 GHz |
| Type: | WR-62 Horn |
| Gain: | 10 dBi |
| Stock: | 0 |
| 2026/06/24 | |
