HS-159-UDR-20A-NF WR-159 Directional Horn Antenna
C-Band Monitoring | 18° Symmetrical Focus | Professional RF Grade
The HS-159-UDR-20A-NF is a high-performance Waveguide Horn Antenna specifically engineered for precision measurement and high-power operations within the 4.9 GHz to 7.05 GHz C-band spectrum. Precision-manufactured from high-grade aluminum and featuring a standard UDR Waveguide Flange, it ensures low VSWR and consistent 20 dBi gain. Its robust 380W power handling and highly directional 18° beamwidth make it an essential radiator for EMI/EMC testing, antenna calibration, and professional Signal Security infrastructure.
Electrical & RF Performance
| Frequency Range | 4.9 - 7.05 GHz |
| Waveguide Standard | WR-159 |
| Standard Gain | 20 dBi |
| Max Power Handling | 380 Watts (CW) |
| 3dB Beamwidth (H/E) | 18° / 18° |
Mechanical & Physical
| Dimensions | 256 x 174 x 311 mm |
| Weight | 1000 g |
| Connector Type | N-Female (Stainless Steel) |
High-Gain Directionality
Delivers a focused 20 dBi gain with symmetrical 18-degree H/E plane beamwidth, providing extreme boresight accuracy for antenna range calibration.
Stainless Steel Interconnect
Equipped with a precision-machined SUS-303 N-Female connector, ensuring exceptional mating durability and stable impedance in high-vibration environments.
Superior Signal Integrity
The precision aluminum construction ensures low VSWR and high structural rigidity, maintaining unwavering stability in demanding Signal Defense operations.
C-Band Spectrum Dominance
Optimized for 4.9-7.05 GHz operation, providing a critical low-loss link for tactical signal management and professional shielding systems.
Contact FT-RF Engineering Division
Contact our engineering team for custom gain requirements, specialized mounting adapters, or alternative waveguide flange patterns.
