| Frequency Range Class | 2.6 GHz - 3.95 GHz (S-Band Microwave Optimization) |
| Nominal Gain (Typical) | 10 dBi |
| V.S.W.R Profile (Max) | 1.25 : 1 (High RF Transmission Efficiency) |
| -3dB Beamwidth (Horizontal) | 56° |
| -3dB Beamwidth (Vertical) | 56° |
| Maximum Power Handling | 300 W (Continuous Wave Limit) |
| Physical Dimensions (L x W x H) | 290 x 143 x 103 mm |
| Net Weight Profile | 98 g (Lightweight Aerospace Profile) |
| Waveguide Size / Flange Type | EIA WR-284 / Standard UDR Interface Layout |
| Connector Interface Port | Premium Stainless Steel N-Female |
| Structural Body Material | High-Grade Machined Aluminum Alloy |
| Manufacturing Origin | Taiwan Design & Made in Taiwan (FT-RF Professional Grade) |
Specifically tuned for the 2.6 - 3.95 GHz spectrum, ensuring high electromechanical accuracy and uniform patterns for industrial and satellite testing fields.
Delivers a uniform 10 dBi gain profile across the entire operating band, making it essential for use as a reliable reference antenna in laboratory setups.
Equipped with a standard UDR waveguide flange and a rugged aluminum body layout for seamless integration with professional RF test equipment.
Uses premium stainless steel N-Female connectors paired with an ultra-low V.S.W.R of 1.25 to ensure permanent mechanical life and stable trace isolation metrics.
Contact our technical engineering division today to request official quote sheets, custom flange alterations, individual calibrated patterns, or technical laboratory support.
