WR-340 (2.2 GHz to 3.3 GHz) 10dbi Waveguide Standard Horn 71/16-Female Antenna

WR-340 (2.2 GHz to 3.3 GHz) 10dbi Waveguide Standard Horn 71/16-Female Antenna

Model No: HS-340-UDR-10A-716

MECHANICAL DRAWING DATASHEET
Model: HS-340-UDR-10A-716
Frequency Range: 2.2 to 3.3 GHz
Gain: 10 dBi
Max Power: 800 W
Connector: 7/16-Female
Stock: 10+  in stock  | Delivery:  5-7 working days
Quantity:
INQUIRY

  • Description & Specification

  • Model: HS-340-UDR-10A-716
  • Waveguide: WR-340
  • Frequency: 2.2GHz to 3.3GHz
  • Gain: 10 dBi
  • Max Power (W): 800W
  • -3dbi beamwidth H-plane:54deg
  • -3dbi beamwidth E-Plane:54deg
  • Size (mm): 123x162x358
  • Weight (g): 1500
  • Waveguide Flange: UDR
  • V.S.W.R: 1.25
  • Body Material: Aluminium
  • Connector: 7/16-Female
